Simply supported beam total length of beam is 1300mm, b= 125mm and h=200mm All
cover is 25mm, with and without steel fiber 1%.
p/2
p/2
1100 mm
Main reinforcement = 4* 8 mm
Stirrups (  2) = 6 mm@ 150mm
200 mm
f'c= 25 MPa , Ec= 4700√𝒇′𝒄 =23500MPa,
v=0.17
fy= 400 MPa , Es= 200000 MPa, v=0.3
steel fiber = Es= 200000 MPa, v=0.3
125 mm
1- Create nodes
Preprocessor
modeling
Node No.
1
2
3
4
5
Create
x-axis
0
25
50
100
125
y-axis
0
0
0
0
0
Nodes
z-axis
0
0
0
0
0
in active C S
