EGR 213 Problem Set 5
1. Two vertical forces are applied to a beam of the cross section shown. Determine the maximum tensile and compressive
stresses in portion BC of the beam. (3 points)
Figure 1
2. A 60-N·m couple is applied to the steel bar shown. Assuming that the couple is applied about the z axis as shown,
determine the maximum stress and the radius of curvature of the bar. Use E = 200 GPa. (3 points)
Figure 2
3. Wooden beams and steel plates are securely bolted together to form the composite member shown. Using the data
given below, determine the largest permissible bending moment when the member is bent about a horizontal axis. (4
points)
Figure 3
1
