Franco De Flaviis
EECS Dept.
University of California, Irvine
EECS 70A
Network analysis
Textbook: Fundamentals of Electric Circuits 7th edition, by C. Alexander, M.
Sadiku, ISBN: 978-1-260-22640-9
Office Hours: EG3339, T/Th: 9.30-10.30 AM.
TA: Roger Bock Filella (rbockfil@uci.edu)
TA lab Sahar Bagherkhani (sbagherk@uci.edu) Saeid Alamdar
(salamdar@uci.edu)
Grading policy:
– 15% Homework (roughly weekly, due at the beginning of the lecture)
– 15% Online Quiz (On EEE, typically one for each lecture on friday)
– 30% Midterm,
– Final 40%
•
•
•
•
•
Course Information
Grading
Homework 15% Quizzes 15% Mid-Term 30% Final exam 40%
Text: Fundamentals of Electric Circuits, 7th Edition by Charles K. Alexander, Matthew N.O. Sadiku
ISBN:978-1-260-22640-9
Magnetically coupled circuits and transformers (Chapter 13)
Week 10 (Mar10-Mar14)
Magnetically coupled circuits (Chapter 13)
Week 9 (Mar3-Mar7)
Power analysis and maximum power transfer. (Chapter 11)
The power factor and complex power (Chapter 11)
Week 8 (Feb28-Feb28)
Impedance in series and parallel. (Chapter 10)
Phasor analysis for AC steady state circuits. (Chapter 10)
Week 7 (Feb17-Feb21)
Phasors. (Chapter 9)
AC steady state circuit analysis (Chapter 10)
The concept of impedance. (Chapter 10)
Week 6 (Feb10-Feb14)
MIDTERM
Inductors and capacitors. (Chapter 6)
First order circuits transient (Chapter 7)
Week 5 (Feb3-Feb7)
Superposition principle. (Chapter 4)
Thevenin's and Norton's theorems. (Chapter 4)
Week 4 (Jan27-Jan31)
Nodal voltage analysis. (Chapter 3)
Branch current analysis. (Chapter 3)
Nodal voltage analysis and Branch current analysis solving strategies. (Chapter 3)
Week 3 (Jan20-Jan24)
Kirkoff's voltage and current laws (Chapter 2).
Resistors connected in series and parallel (Chapter 2).
Delta/Y transformation (Chapter 2).
Week 2 (Jan13-Jan17)
Basic concepts of voltage current and power. (Chapter 1).
Basic circuits elements and their characteristics (Chapter 1).
Ohm's law and simple resistive circuits (Chapter 2).
Week 1 (Ja6-Jan10)
Topic covered by week: (note this is an approximate schedule)
Course outcome
· Students are able to solve DC circuits using Ohm's law, and Kirkoff's law including power consumption.
· Students are able to apply Thevenin's, Norton's and superposition principles to DC circuits.
· Students are able to solve AC circuits in steady state regime.
· Students are able to compute power consumption including active and reactive power in AC circuits.
· Students are able to analyze mutually coupled circuits.
Prof. Franco De Flaviis (email: franco@uci.edu)
Lecture T/TH 8:9.20 (PCB 1100) Office hours T/TH 9.30-10.30 (EG2233)
Network Analysis (70A)
Complains/inquiries : You have 1 week from the time you receive your homework or exam to identify
omissions or incorrect grading. After one week your paper will no longer be considered for re-grading.
Final Examination: The final examination will be from all the course material covered but
mostly will focus on the material covered after the midterm. A missed final will be dealt with
according to the university regulations on incompletes and withdrawals.
will be absolutely NO "make-up" exams. In case you miss a mid-term for reasons beyond your
control, weight of the mid-term will be added to the final examination.
Midterm: There will be one mid-term examination, carrying 30% weight. Please note that there
Quizzes: Short quizzes will be given weekly to make sure that you stay abreast with the lectures.
There will be absolutely NO "make-up" quiz. However, one quiz with the lowest score will be
dropped.
Homework: Homework for practicing the concepts learned in the lectures will be assigned on a
weekly basis with few exceptions. Homework are typically assigned on Thursday and due the
following Thursday. Late work will not be accepted and makeup homework will not be
assigned.
Location:
Room: ET 202
Room: ET 202
Room: ET 202
Room: ET 202
Room: ET 202
Room: ET 202
Student A is responsible for lab report for Experiment 1
Student B is responsible for the lab report for Experiment 2
Student C is responsible for lab report for Experiment 3
The rotation then repeats, so Student A is responsible for Experiment 4, and so on
By the end of the quarter, each student will be responsible for three lab reports and 9 prelabs.
Although report responsibilities rotate, all group members are expected to actively participate in
every experiment and remain fully aware of the procedures and concepts involved at all times. Student
preparedness and participation will be randomly assessed by the teaching assistant throughout the
quarter. These assessments collectively account for 25% of the final course grade.
•
•
•
•
Group Size and Responsibilities
Students must work with their assigned lab partners during each laboratory session. Each group may
consist of a maximum of three students.
Responsibility for lab reports will rotate among group members while each member is responsible for
the prelab for every experiment. For example, in a group of three students (A, B, and C):
Lab 9, week 9: Complex power
Covered topics:
Lab 1, week 1: Lab orientation
Lab 2, week 2: Ohms law and basic I-V curves
Lab 3, week 3: Resistor networks, Power
Lab 4, week 4: Network analysis KCL and KVL
Lab 5, week 5: Thevenin, Northon, superposition
Lab 6, week 6: AC signals basic AC circuits
Lab 7, week 7: Impedance networks
Lab 8, week 8: Impedance networks and phasors
Lab content and related materials:
Lab notes with experiments will be posted on line every week, there is no official text book for this
laboratory, but all the theory is covered in EECS70A, the text book used for 70A is:
Fundamentals of Electric Circuits, 7th edition by Charles K. Alexander, Matthew N.O. Sadiku
ISBN:978-1-260-22640-9
Lab section
Meeting Time:
1 Monday: 11AM- 1.50PM
2 Monday: 2PM- 4.50PM
3 Monday: 7PM- 9.50PM
4 Tuesday: 11AM- 1.50PM
5 Tuesday: 7PM- 9.50PM
6 Thursday: 7PM- 9.50PM
Email: franco@uci.edu
Office: EG 2233
Instructor: Prof. Franco De Flaviis
EECS 70AL: Network Analysis Laboratory (1 Unit)
Winter 2026
20% (assessed over 3 reports over the quarter)
25%
55% (assessed over 3 reports over the quarter)
2. Laboratory Skills and Ability
Students are required to demonstrate proficiency in the effective use of laboratory equipment. This
includes, but is not limited to, the proper operation of the oscilloscope, power supply, signal generator,
and other lab instruments. As part of the lab ability assessment, students may be asked to perform
additional experimental steps and explain or comment on any observed phenomena. Each week, the TA
will evaluate a different group member to ensure that all students demonstrate individual competency
throughout the quarter.
1. Pre-Lab Reports and Lab Grades
Pre-lab assignments will be checked by the Teaching Assistant (TA) at the beginning of each lab session.
To receive credit for a lab, all collected data must be reviewed and approved by a TA before you leave the
laboratory. Please do not disassemble your circuits until this data review has been completed. Postprocessing of experimental data is an essential component of the final grade. Students are expected to
present their results clearly and comprehensively in a properly formatted lab report. The quality of data
analysis, presentation, and discussion will be reflected in the final lab grade. Lab reports are due the
following week. The late submission policy for lab reports is the same as the late homework policy.
Grading:
1. Pre Lab
2. Lab ability evaluated by the TA:
3. Lab report
JOULE
N •m
=
COULOMB A • s
IT IS ESSENTIAL THAT OUR NOTATION ALLOWS US TO DETERMINE WHICH POINT
HAS THE HIGHER VOLTAGE
VOLTAGE IS ALWAYS MEASURED IN A RELATIVE FORM AS THE VOLTAGE DIFFERENCE BETWEEN TWO
POINTS
VOLT =
DIMENSIONALLY VOLT IS A DERIVED UNIT
1C
+ a
ONE DEFINITION FOR VOLT
TWO POINTS HAVE A VOLTAGE DIFFERENTIAL OF
ONE VOLT IF ONE COULOMB OF CHARGE GAINS
(OR LOSES) ONE JOULE OF ENERGY WHEN IT
MOVES FROM ONE POINT TO THE OTHER
THE CHARGE GAINS
b IF
ENERGY MOVING FROM
a TO b THEN b HAS HIGHER
VOLTAGE THAN a.
IF IT LOSES ENERGY THEN
b HAS LOWER VOLTAGE
THAN a
CONVENTIONS FOR VOLTAGES
V
POINT A HAS 2V MORE
THAN POINT B
POINT A HAS 5V LESS
THAN POINT B
IF THE NUMBER V IS POSITIVE POINT A HAS V
VOLTS MORE THAN POINT B.
IF THE NUMBER V IS NEGATIVE POINT A HAS
|V| LESS THAN POINT B
THE + AND - SIGNS
DEFINE THE REFERENCE
POLARITY
A NEGATIVE VALUE FOR
THE CURRENT INDICATES
FLOW IN THE OPPOSITE
DIRECTION THAN THE
REFERENCE DIRECTION
A POSITIVE VALUE FOR
THE CURRENT INDICATES
FLOW IN THE DIRECTION
OF THE ARROW (THE
REFERENCE DIRECTION)
THE UNIVERSALLY ACCEPTED CONVENTION IN
ELECTRICAL ENGINEERING IS THAT CURRENT IS
FLOW OF POSITIVE CHARGES.
AND WE INDICATE THE DIRECTION OF FLOW
FOR POSITIVE CHARGES
-THE REFERENCE DIRECTION-
IT IS ABSOLUTELY NECESSARY TO INDICATE
THE DIRECTION OF MOVEMENT OF CHARGED
PARTICLES.
b
I ab = 5 A
I ab = 3 A
I ab = −3 A
a 3A b a − 3A b
5A
POSITIVE CHARGES
FLOW LEFT-RIGHT
POSITIVE CHARGES
FLOW RIGHT-LEFT
I ba = 3 A
I ab = − I ba
I ba = −3 A
a − 3A b a 3A b
a
IF THE INITIAL AND TERMINAL NODE ARE
LABELED ONE CAN INDICATE THEM AS
SUBINDICES FOR THE CURRENT NAME
THE DOUBLE INDEX NOTATION
Current sign convention
• An ideal voltage source has no internal
resistance.
• It also is capable of producing any amount of
current needed to establish the desired
voltage at its terminals.
• Thus we can know the voltage at its terminals,
but we don’t know in advance the current.
Ideal Voltage Source
• Current sources are the opposite of the
voltage source:
• They have infinite resistance
• They will generate any voltage to establish the
desired current through them.
• We can know the current through them in
advance, but not the voltage.
Ideal Current Source
• Both the voltage and current source ideally
can generate infinite power.
• They are also capable of absorbing power
from the circuit.
• It is important to remember that these
sources do have limits in reality:
• Voltage sources have an upper current limit.
• Current sources have an upper voltage limit.
Ideal sources
Symbol
Some practical resistors
