ENGR 2210
Your Name:
Homework #01
Due: 02-05-2024, by class time.
Note.
1.
Please print this document and write your solutions and answers directly on it.
2.
If you need more space for your solutions, feel free to add additional pages.
3.
Write your name on every page.
4.
After completing all calculations, please round your answers to one decimal place (e.g., 345.5).
5.
Your grade will be more influenced by your effort and attempt to solve the problems than by simply having
the correct answers.
1. If 𝜃 = 30°, 𝐹2 = 6 𝑘𝑁, determine the magnitude of the resultant force acting on the
plate and its direction measured clockwise from positive 𝑥 axis.
ENGR 2210
Your Name:
Homework #01
Due: 02-05-2024, by class time.
2. If the force in each chain has a magnitude of 60 lb, express each force as a Cartesian
vector and determine the magnitude and coordinate direction angles of the resultant force.
