1. Use the Node Voltage Method to analyze the circuit below. How many nodes are
there?
2. How many dependent nodes are there (m)?
3. How many KCL equations are needed to solve this circuit using the Node Voltage
Method?
4. What is the Voltage at each node?
5. Use the Mesh Current Method to analyze the circuit below. How many meshes (n)
are there?
6. How many dependent meshes (m) are there?
7. What is V2?
8. In the circuit shown below, calculate the Thevenin resistance (Rth).
9. What is the Thevenin Voltage
10. For maximum power transfer, we need to change the load resistance. What value for
the load resistor would give maximum power transfer to the load?
11. In the circuit shown below, calculate the Norton resistance (Rn).
12. What is the Norton current (In).
