Product Data Sheet
Exaton 15W/Exaton 19.9.L
S 'Submerged arc welding'
Prepared by
Qualified by
Approved by
Reg no
Cancelling
Reg date
Page
Nicklas Folkeson
P-O Oskarsson
Paolo Torchiana
EN009935
EN009156
2022-04-08
1 (2)
REASON FOR ISSUE
Wire Classifications updated (Werkstoffnummer amended) and new layout.
GENERAL
Exaton 15W is a basic welding flux for submerged arc welding giving good slag removal and a fine bead
appearance. Its relatively high basicity makes it suitable for joining of the austenitic and duplex stainless steel
when high impact strength is desired.
Exaton 19.9.L is a filler material for joining austenitic stainless steels, e.g. ASTM 304, 304L (18Cr/8Ni/ELC),
for cryogenic applications and meets the requirements of ASME Section VIII, Division 1, UHA 51 ((a) (3) (-a)
(-1)) and ferritic or martensitic stainless steels with maximum 19% Cr.
This SAW combination is approved by TÜV for use at cryogenic temperatures down to -196°C.
It is also suitable for joining stainless steels of 18Cr/8Ni/Nb types, e.g. ASTM 347, for service temperatures up
to 350°C (660°F).
CLASSIFICATIONS Flux
APPROVALS
EN ISO 14174
VdTÜV
S A AF 2
CLASSIFICATIONS Weld Metal
Not applicable
CLASSIFICATIONS Wire Electrode
EN ISO 14343-A
SFA/AWS A5.9
Werkstoffnummer
S 19 9 L
ER308L
~1.4316
CHEMICAL COMPOSITION
All Weld Metal (%) Wire/Strip (%)
C
Si
Mn
P
S
Cr
Ni
Mo
Co
Cu
N
FN WRC-92
Nom
Nom
0.02
0.6
1.2
0.025
0.011
19.3
10
0.15
0.1
0.1
0.09
6
<0.025
0.4
1.8
<0.025
<0.015
20
10
<0.5
<0.20
<0.3
<0.08
MECHANICAL PROPERTIES OF WELD METAL
All Weld Metal
Condition Rp0.2
[MPa/ksi]
Min
As welded
Comments:
Typ
390/57
Rm
[MPa/ksi]
Min
Max
Typ
560/81
A5
[%]
Min Typ
35
06589
Product Data Sheet
Exaton 15W/Exaton 19.9.L
S 'Submerged arc welding'
Prepared by
Qualified by
Approved by
Reg no
Cancelling
Reg date
Page
Nicklas Folkeson
P-O Oskarsson
Paolo Torchiana
EN009935
EN009156
2022-04-08
2 (2)
MECHANICAL PROPERTIES OF WELD METAL
Condition
As welded
Temp
[°C/°F]
20/68
-196/-321
Charpy V
[J/ft-lb]
Min
Typ
90/67
35/26
Comments:
OTHER DATA
CORROSION RESISTANCE:
Exaton 19.9.L has good resistance to general corrosion and due to its low carbon content, good resistance to
intercrystalline corrosion. It also has good resistance to oxidizing agents.
Welding data: Direct current with electrode positive is normally used.
Please note that the Werkstoff Nr. corresponds to the base material of the same grade.
